1"DR. Sockets- 6PT (mm)
Product Specification
Product Description
Product Specification
| Item Nr. | ||||||
|---|---|---|---|---|---|---|
| 528636 | 36 | 51.0 | 45.0 | 28 | 65 | 470 |
| 528638 | 38 | 54.0 | 45.0 | 30 | 65 | 520 |
| 528641 | 41 | 57.0 | 45.0 | 32 | 70 | 570 |
| 528646 | 46 | 65.0 | 50.0 | 34 | 75 | 870 |
| 528650 | 50 | 70.0 | 55.0 | 34 | 75 | 1050 |
| 528654 | 54 | 74.0 | 57.0 | 40 | 80 | 1100 |
| 528655 | 55 | 76.0 | 57.0 | 40 | 80 | 1250 |
| 528658 | 58 | 79.0 | 57.0 | 40 | 80 | 1300 |
| 528660 | 60 | 82.0 | 57.0 | 42 | 84 | 1500 |
| 528663 | 63 | 86.0 | 57.0 | 44 | 87 | 1660 |
| 528665 | 65 | 88.0 | 57.0 | 44 | 87 | 1660 |
| 528667 | 67 | 90.0 | 57.0 | 46 | 90 | 1800 |
| 528670 | 70 | 94.0 | 68.0 | 48 | 93 | 2200 |
| 528671 | 71 | 95.0 | 68.0 | 48 | 93 | 2280 |
| 528675 | 75 | 100.0 | 68.0 | 52 | 97 | 2400 |
| 528677 | 77 | 102.0 | 68.0 | 54 | 103 | 2600 |
| 528680 | 80 | 105.0 | 68.0 | 54 | 103 | 2720 |
Product Description
- Metric size designed according to DIN 3124, ISO 2725-1
- Square drive as per DIN 3120, ISO 1174
- Chrome Vanadium
- Country of Origin：Taiwan
